Well Pressure Tank Replacement in Phoenix, AZ

Reliable Well Pressure Tank Replacement Services in Phoenix, AZ

Bladder Pressure Tank Replacement in Phoenix

Bladder tanks hold water inside a flexible butyl bag surrounded by pressurized air. When the bag ruptures, water fills the whole tank, there is no air cushion and the pump short cycles. A quick test is pressing the air valve on top, since water spitting out means the bladder has failed. We replace the tank, set the new pre-charge and confirm the pump runs a full cycle. Most bladder tank swaps take about two to three hours.

Diaphragm Pressure Tank Replacement in Phoenix, AZ

Diaphragm tanks like the Amtrol Well-X-Trol use a fixed membrane that separates air above from water below. They are durable, but the steel shell can rust through at the base after years of condensation in a hot well house. We replace corroded diaphragm tanks and check the stand and fittings under them. The new tank is leveled and supported so it does not stress the piping. This restores steady pressure to every faucet.

Pressure Tank Sizing and Upsizing in Phoenix

Many older systems have a tank that is too small for the pump, so the motor starts every time someone washes their hands. Tank size is based on drawdown, which is the usable water stored between cut-out and cut-in pressure. For example, a 10 gallon per minute pump usually needs at least 10 gallons of drawdown for a one minute run time. That often means an 80 to 119 gallon tank rather than the 20 gallon unit that came with the home. Upsizing is one of the best ways to extend pump life.

Pressure Switch Replacement in Phoenix, AZ

The pressure switch tells the pump when to start and stop, typically at 30/50 or 40/60 psi. Pitted contacts, ant nests and a clogged sensing nipple are common causes of failure in Arizona well houses. We replace worn switches with Square D or similar models and clean or replace the nipple below it. A low-pressure cutoff switch can also be added to stop the pump if the well runs dry. We set the switch to match your new tank's pre-charge.

Tank Tee, Gauge and Relief Valve Replacement in Phoenix

The tank tee is the manifold that connects the tank, switch, gauge, relief valve and drain. Galvanized tees corrode and restrict flow, especially with sandy or mineral-heavy water. We replace them with brass or stainless steel tank tees that hold up much longer. A new liquid-filled gauge gives accurate readings, and a fresh relief valve protects against a stuck switch. These small parts make a big difference in reliability.

Constant Pressure System Conversion in Phoenix, AZ

A constant pressure system pairs a variable speed drive like the Franklin SubDrive or Grundfos SQE with a smaller pressure tank. The pump speeds up or slows down to hold a set pressure, so showers do not fade when a sprinkler kicks on. These systems cost more, often $2,500 to $5,000, but they eliminate pressure swings. They also reduce hard starts on the motor. We explain whether your well and pump are good candidates.

Large Capacity Tanks for Ranch and Commercial Wells in Phoenix

Properties with livestock, irrigation or more than one home on a well need more storage than a single residential tank. We install multiple tanks manifolded together or large capacity models over 100 gallons. Proper sizing keeps big three-phase pumps from cycling too often. We also check the check valves and pressure ratings on the distribution lines. Work is scheduled to keep water downtime short for animals and occupants.

Emergency Pressure Tank Replacement in Phoenix, AZ

A ruptured tank can leave you with no water or a pump that never shuts off, which can burn up the motor quickly. If the pump is running nonstop, turn off its breaker and call (928) 470-9009. We carry common tank sizes and fittings for same-day replacement. Once water is restored, we test the pump's amp draw to make sure it was not damaged. Fast action can save you the cost of a new pump.
